Stable Temperature Hot / Cold Fluid Chuck System
	Signatone’s Stable Temperature Fluid Chuck Systems are ideal for temperature tests that require precise stablilty and high resolution control in the range of -15oC to +70oC. The systems includes a gold plated wafer chuck and a self contained heater/chiller system that cycles temperature conditioned water through the wafer chuck. Chucks are available in 6” and 8” diameters.
Temperature Range of -15oC to +70oC 0.1oC Resolution CFC-Free Refrigeration System Manual or Automatic Control Digital Controller with proportional Control RS-232 Interface Ideal for liquid crystal hot spot detection use

Signatone Probe Stations Signatone offers a wide array of probe stations that can accept the Stable Temperature Hot / Cold Fluid Chuck Systems.

To Probe Stations Page.
