Principal Features
• Easily pre-set to measure wafer from one to nine positions
• Eight inch wafer capacity on vacuum chuck - six inch model available
• Lever-operated probe with switched current leads to prevent arcing
• Repositioning accuracy within +/- 1 mm
• Precision low maintenance slides
• Shrouded measuring area to eliminate light and electrical interference

The instrument comprises a white powder-paint coated metal base carrying a Delrin column supporting the vertical slide, operating lever shaft, and micro-switch. The vertical slide carries the probe head, secured by a clamp screw. The probe head is positioned so that the micro-switch does not pass current until the probes have made contact, lost motion ensures that the current is switched off before the probes are raised.

The wafer table slides towards the operator to enable the wafer to be centrally positioned, after which the vacuum control valve can be operated to secure it in position. Annular rings allow each wafer size to be centered. When the table is pushed to the limit of its travel, a measurement can be made at it's center. Four radial positions at right-angles are denoted by a spring-loaded index ball incorporated in the rotary table. The radial distance of measurement is denoted by a similar arrangement on the linear slide index plate. Unwanted settings can be blocked off by easily removed screws. So that, for example, one could choose to measure at the center and four points at 50mm radius.

A grounded metal shield screens the wafer from light and electrical noise during measurement. It is arranged that the shield rises when the probe head is fully lifted to permit loading.

Operating instructions for the Multiposition Wafer Probe - 6" model

Operating instructions for the Multiposition Wafer Probe - 8" model
